The gigabit dual-band indoor/outdoor access point OAP1200 offers a concurrent data rate as high as 1167 Mbps. Equipped with 2 omni-directional high-gain antennas, OAP1200 provides a maximum coverage radius of 200 meters. OAP1200 can be installed either on the wall or around a pole. OAP1200 can meet different requirements by connecting antennas of different specifications to the standard RP-SMA connectors. With the IP65 enclosure, OAP1200 is designed for wireless coverage in factories, warehouses and other harsh outdoor environments. Model OAP1200 Category Outdoor AP Dimension 194.7*83*42.1 mm Interface One 10/100/1000 Mbps Ethernet Port (PoE) Button 1*Reset LED indicator 1 x SYS Maximum Power Consumption 11.5w Power Supply 802.3af & 24V 0.5A Passive PoE Max. Number of Clients 256 Recommended Clients 38 Antenna 2.4GHz: 2 x 4dBi 5GHz: 2 x 4dBi 2.4GHz maximum power 23 /-1.5dBm 5GHz maximum power 23 /-1.5dBm Reception Sensitivity 802.11b -93 dBm 2.4 GHz 802.11n (MCS7) -73dBm 5 GHz 802.11a -93 dBm 5 GHz 802.11n (MCS7) -74 dBm Frequency Range 2.4GHz&5GHz Standard&Protocol 802.11a/b/g/n/ac(wave2) Maximum wireless speed 2.4GHz: 300Mbps 5GHz: 867Mbps Bandwidth 20MHz/40MHz/80MHz Operating Mode AP/Client AP Max. No. of SSID 2.4GHz: 8 5GHz: 4 Hide SSID Supported OFDMA Supported Beamforming Supported Fast roaming`a3`a8802.11k/v/r`a3`a9 Supported WEP Supported WPA-PSK Supported WPA2-PSK Supported WPA Supported WPA2 Supported Access control Supported Adjustable power transmit Supported Automatic channel Supported AP isolation Supported Guest network Supported Connected clients control Supported RSSI Threshold Supported Weak signal terminal elimination Supported Prioritize 5 GHz Supported VLAN tagging for SSID Supported LED control Supported MU-MIMO Supported Diagnostics tool Supported Reboot at specified interval Supported Scheduled reboot Supported Device management Web management Router management System logs Supported Firmware upgrade Supported Reboot Supported Reset Supported Backup configuration Supported Restore configuration Supported Default IP 192.168.0.254 Default username admin Default password admin Operation Temperature -30℃ ~ 50℃ Operating Humidity 10%~90% non-condensing Storage Temperature -30℃ ~ 70℃ Storage Humidity 10%~90% non-condensing
