Power Input voltage PoE IEEE 802.3af / 802.3at Type 1, Class 3 24 VAC `b110% 12-26 VDC `b110% PoE and auxiliary power can be connected simultaneously for redundant operation Power Consumption (typical / maximum) PoE: 7 W / 13 W 24 VAC: 7.1 W – 12 VA / 13 W – 25 VA 12-26 VDC: 7.5 W / 16 W Sensor Sensor type 1/1.8‑inch CMOS Effective pixels 3264 (H) x 1840 (V) pixels, 6.0MP (approx.) Starlight sensitivity (3.9 to 10 mm lens) Measured according to IEC 62676 Part 5 (1/25, F1.5) Color 0.040 lx Mono 0.0059 lx Starlight sensitivity (12 to 40 mm lens) Measured according to IEC 62676 Part 5 (1/25, F2.3) Color 0.084 lx Mono 0.0135 lx Dynamic range Wide Dynamic Range 120 dB WDR Measured according to IEC 62676 Part 5 107 dB WDR (3.9 to 10 mm lens) 106 dB WDR (12 to 40 mm lens) Video streaming Video compression H.265; H.264; M- JPEG Sensor modes 25 fps, HDR, 3072 x 1728 (5.3 MP) 30 fps, HDR, 3072 x 1728 (5.3 MP) 25 fps, 3264 x 1840 (6 MP) 30 fps, 3264 x 1840 (6 MP) Streaming Multiple configurable streams in H.264, H. 265 and M-JPEG, configurable frame rate and bandwidth. Regions of Interest (ROI) Bosch Intelligent Streaming Camera latency 120 ms (6 MP, 30 fps) GOP structure IP Frame rate 1-30 fps Signal-to-Noise Ratio (SNR) >55 dB Video functions – color Adjustable picture settings Contrast, Saturation, Brightness White Balance 2500 to 10000K, 4 automatic modes (Basic, Standard, Sodium lamp, Dominant color), Manual mode and Hold mode The FLEXIDOME IP starlight 8000i cameras offer starlight technology and High Dynamic Range with 6 megapixel resolution to provide crisp and highly detailed images even in extreme low-light situations. It delivers excellence in video security and data management and has built-in state-of-the-art Intelligent Video Analytics as standard. It’s rugged and aesthetic design makes the camera suitable for any indoor or outdoor installation. The camera’s remote commissioning functionality makes sure installation and commissioning can be done in very little time. Using a PC or a mobile device with the Bosch Project Assistant app, you can pan, tilt, roll and zoom (PTRZ) and point the camera to the required field of view with a single click – without ever having to touch the camera or lens. What`s In The Box 1 x Flexidome Camera 1 x Template 1 x Bracket Connectors
