Features1. Higher Power : Delivers twice power of lead acid battery ,even high discharge rate, while maintaining high energy capacity2. Lighter Weight : About 40% of the weight of a comparable lead acid battery . A " drop in" replacement for lead acid batteries. 3. Long lifespan: Offers up to 20 times longer cycle life and five times longer float/calendar life than lead acid battery, helping tominimize replacement cost and reduce total cost of ownership. 4. Superior Safety: Lithium Iron Phosphate chemistry eleminates the risk of explosion or combustion due to high impact overcharging or short circuit situation5. Easy InstallationBasic Parameters48150Nominal Voltage (V)51.2Nominal Capacity (Wh)7680Usable Capacity (Wh)6144Dimension (mm)480*678*178Weight (Kg)60Discharge Voltage (V)45.6-57.6Charge Voltage (V)56-57.6Charge / Discharge Current (A)50A(Recommend)100 A(Max)Cycle Life>6000,25Power Consumption<10W WorkMonitoring ParametersSystem voltage,current,cell voltage,cell temperature,module temperatureSOCIntelligent algorithmCommunicationCAN/DRY CONTACTOperating Temperature Range-10~50Transport or Storage Temperature Range-20-45Humidity15%~85% (No Condensing) 1.Put battery modules into cabinet and connect the cablesNote: If customer needs cabinet, please contact our sales 1.Put the battery into the cabinet2.Drive the 4 pcs screws 3.Connect the cables between battery modules 4.Connect the cables to inverter 2. Power OnDouble check all the power cable and communication cable (1) ON/OFF Switch on all the battery modules and the green LED light below will be on (2) Set ADD Set ADD follow ADD instruction, pack 1 will be host, others are slaves SUNWAY LITHIUM BATTERY FACTORYSUNWAY LITHIUM BATTERY PACKAGESUNWAY LITHIUM BATTERY PROJECT
