Specifications Model Parameters Model CS-DB2C-A0-1E3WPBR Camera Parameters Image Sensor 1/2.7″ Progressive Scan CMOS (Supports low light sensitivity) Lens 2.2
[email protected], Ultra FOV 160`b0 Vertical Day & Night IR-cut filter with auto-switching IR Range Max. 6 m (20 ft) Video Parameters Max. Resolution 1536 x 1536 FHD DNR 2D/3D DNR Video Compression H.265/H.264 Frame Rate Max: 15fps; Self-Adaptive during network transmission PIR Sensor Sensing Angle 100`b0 Sending Distance Max. 5 m (16.4 ft) Sensitivity User adjustable (High, Medium and Low Sensitivity) Interface Audio Input Built-in high-sensitivity microphone Audio Output Built-in high-power speaker Reset button Yes Network Parameters Intelligent Alarm PIR Person Detection Tamper Alarm Sound and light anti-dismantling alarm (support alarm to mobile phone) Video Intercom Long-distance video two way talk Protocol EZVIZ cloud proprietary protocol Interface Protocol EZVIZ cloud proprietary protocol Wi-Fi Parameters Wi-Fi Standard IEEE802.11b/g/n Frequency Range 2.4 GHz ~ 2.4835 GHz Channel Bandwidth Supports 20 MHz Security 64/128-bit WEP,WPA/WPA2,WPA-PSK/WPA2-PSK Transmission Rate 11b: 11Mbps, 11g: 54 Mbps, 11n: 150 Mbps General Operation Conditions -10`b0C to 45`b0C (14`b0F to 113`b0F), Humidity 95% or less (non-condensing) Ingress Protection Grade No IP Grade Weight 206 g (0.45 lb) Size 146 mm x 60 mm x 34 mm (5.75” x 2.36” x 1.34”) Battery Capacity 5200mAh rechargeable lithium battery Power Supply DC5V`b110% Power Consumption Max.7.5W Model / Chime Size 100 x 54 x 37 mm (3.94” x 2.13” x 1.46”) Power Supply AC 100 ~ 240V Wi-Fi Standard IEEE802.11b/g/n Audio Output 65dB within 3 meters Storage Supports TF card up to 256 G Weight 120 g (0.26 lb) In the box: In the box: Doorbell ; Chime ; Mounting Plate ; Screw Kit ; Foam Sticker ; Drill Template ; Pin ; Power Cable ; Quick Start Guide Certifications: Certifications: UL / FCC / CE / WEEE / REACH / RoHS
