■ 6000 cycles @ 80% DOD, 25 °C for effectively lower total of ownership cost. ■ Safe, reliable and long life ■ Support series or parallel connection ■ Battery Management System (BMS) is incorporated against abuse. ■ Superior charge/discharge efficiency ■ Low maintenance batteries with stable chemistry. ■ Extreme heat tolerance ■ Lithium batteries provide more Wh/Kg while also being up to 1/3 the weight of its SLA equivalent. ■ Support Bluetooth and APP to view battery information (optional) Technical Data LP15-1250 LP15-12100 LP15-12150 LP15-12200 LP15-24100 LP15-24150 LP15-24200 Nominal Voltage 12.8V 25.6V Nominal Capacity 50Ah 100Ah 150Ah 200Ah 100Ah 150Ah 200Ah Nominal energy 640Wh 1280Wh 1920Wh 2560Wh 2560Wh 1920Wh 5120Wh Max. output power 0.6KW 1.2KW 1.2KW 1.2KW 2.5KW 2.5KW 2.5KW Life Cycles 6000 cycles @ 80% DOD, 25°C Recommended Charge Voltage 14.6V 29.2V Recommended Charge Current 20A 40A 20A 40A End Of Discharge Voltage 10V 20V Standard Method Charge 10A 20A 30A 40A 20A 30A 40A Discharge 25A 50A 75A 100A 50A 75A 100A Maximum Continuous Current Charge 25A 50A 75A 100A 60A 75A 100A Discharge 50A 100A 100A 100A 100A 100A 100A BMS Cut-Off Voltage Charge 15.4 V (3.85V/Cell) 30.8 V (3.85V/Cell) Discharge 9.2 V (2s) (2.3V/Cell) 18.4 V (2s) (2.3V/Cell) Temperature Charge 0~45°C Discharge -10~55°C Storage Temperature -5~35°C Shipment voltage ≥12.8V ≥25.6V Case Material ABS PC Machine Dimension (W*H*D) (mm) 260*167*210 339*185*218 339*185*218 502*186*243 502*186*243 522*240*218 522*240*218 Package Dimension (W*H*D) (mm) carton box 315*225*260 385*230*260 385*230*260 520*225*280 520*225*280 545*285*288 545*285*288 N.W (kg) 7.5 12 15 21 20 29 37 G.W (kg) carton box / 13 16 22 21 31 38 * Variations in dimensions and weights may occur due to production batches. Charge Retention And Capacity Recovery Capability Standard charge the battery, and then put aside at room temperature for 28d or 55°C for 7d, Charge retention rate≥90%, Recovery rate of charge≥90% Warranty 5 years Certification & Standards CE-EMC (EN 61000-6-3 A1 AC EN IEC 61000-6-1); UN38.3/ MSDS
