■ Smart LCD setting(Working modes, Charge Current, Charge Voltage, etc.) ■ Built-in MPPT 180A solar charge controller ■ MPPT Efficiency max 98% ■ Combining solar system, AC utility, and battery power source to supply continuous power ■ Multiple operations: basic Grid-tie, Off-Grid, Grid-Interactive ■ Support CAN, RS485 monitoring function MODEL PH30-10048-T PH30-12048-T Nominal Battery System Voltage 48VDC INVERTER OUTPUT Rated output power 10000W 12000W Output wave Pure sine wave Nominal output voltage 230 VAC (P-N) / 400 VAC (P-P) Nominal output current 14.3A per phase 17.4A per phase Nominal output frequency 50 Hz / 60 Hz Rate of wave distortion(THD)(Linearity loads) Off grid≤2%; Grid discharge ≤3%; Grid charge ≤3% Peak efficiency ≥93% Overload capability 100%<load≤110%,30 minutes; 110%<load≤125%,1 minutes; 125%<load≤150%,30 seconds; load<150%,10 seconds; Short circuit,5 seconds AC INPUT AC input maximum current 26.0A per phase 34.8A per phase Nominal frequency 50Hz / 60Hz Acceptable input voltage range Defaults 186Vac ~253Vac per phase;Narrow 174Vac ~272Vac per phase; Wide 95Vac ~272Vac per phase BATTERY Type of Battery Lithium battery or lead-acid battery Nominal Voltage 48VDC Low Voltage Protection Point Charger 34.0VDC; Inverter 40.0VDC Absorption Voltage 50.0VDC Refloat Voltage 54.8VDC Float Voltage 57.2VDC SOLAR CHARGER & AC CHARGER PV Open Circuit Voltage 145VDC Max Solar Charging Current 60A per channel Max AC Charging Current 60A per phase 80A per phase Max Charging Current 120A per phase 140A per phase MECHANICAL SPECIFICATIONS Mounting Floor installation Machine Dimension (W*H*D)(mm) 392*828*629 Package Dimension (W*H*D)(mm) 513*1031*700 N.W(kg) 128 140 G.W(kg) 133 160 OTHER Communication terminal RS485 / CAN bus Operating Temperature Range 0℃ ~ 50℃ Environmental Protection Rating IP20 Ambient humidity 0 — 90% relative humidity (non-condensing) Altitude ≤2000m CERTIFICATION & STANDARDS EN IEC62368-1 CE-LVD (EN IEC62109-1, EN IEC62109-2) Rohs-(2011/65/EUand2015/863/EU) CE-LVD (BS IEC62109-1:2010, BS EN IEC62109-2:2011) UKCA
