■ 100% unbalanced output, each phase max. output up to 50% rated power ■ Max. 6 pcs parallel for on-grid and off-grid operation ■ AC couple to retrofit existing solar system ■ Support multiple batteries parallel ■ Max. charging/discharging current of 240A ■ Support storing energy from diesel generator ■ 48V low voltage battery, transformer isolation design ■ IP66 water-proof and dust-proof ■ “Time of use” function: a maximum of 6 time segments can be set ■ Wifi monitoring MODEL PH11-5KL3-EU PH11-6.5KL3-EU PH11-8KL3-EU PH11-10KL3-EU PH11-12KL3-EU Rated power 5000W 6500W 8000W 10000W 12000W BATTERY INPUT DATA Battery type Lead-acid battery / Lithium battery Battery voltage 48V Battery voltage range 40~60V Charging curve 3-stage adaptive with maintenance/Equalization Charging Strategy for Li-lon Battery Self-adaption to BMS Over-current protection/ Over-temperature protection Yes / Yes Maximum charging/discharging power 5000W 6500W 8000W 10000W 12000W Maximum charging/discharging current 120A 150A 190A 210A 240A PV STRING INPUT DATA Max. DC Input Power 6500W 8450W 10400W 13000W 15600W Rated PV Input Voltage 550V Maximum DC voltage 800V Start-up Voltage 160V Minimum voltage for grid connection 310V Full Load DC Voltage Range 350-650V Enter high voltage error recovery point 800V MPPT voltage range 200~650V Maximum input current 13A/13A 13A 26A No.of MPP Trackers 2 No.of Strings per MPP Tracker 1 1 2 1 AC INPUT/OUTPUT DATA Rated AC Input/ Output Power 5000W 6500W 8000W 10000W 12000W Max AC Input/ Output Power 5500W 7150W 8800W 11000W 13200W AC Input/ Output Rated Current 7.6/7.2A 9.8/9.42A 12.1/11.6A 15.2/14.5A 18.2/17.4A Max AC Input/ Output Current 8.4/8A 10.8/10.4A 13.4/12.8A 16.7/15.9A 20/19.1A Max. Three-phase Unbalanced Output Current 11.4/10.9A 14.7/14.1A 18.2/17.4A 22.7/21.7A 27.3/26.1A Power Factor Adjustment Range 0.8 leading to 0.8 lagging Rated Input/Output Voltage 220/380,230/400Vac Rated Input/Output Grid Frequency/Range 50/60;45~55/55-65 Grid Type Three Phase Total Harmonics Current Distortion (THDi) <3% (of nominal power) DC Current Injection <0.5% In EFFICIENCY Max. Efficiency ≥97.6% Euro Efficiency 97.0% PROTECTION Integrated Islanding protection, PV input polarity reverse protection, insulationresistance detection, surge protection,leakage current monitoringprotection,output current protection, output short circuit protectionoutput overvoltage protection Surge Protection DC Type III/AC Type III Overvoltage Category DC Type II/AC Type III GENERAL DATA Operating Temperature Range (°C) -25°C to 60°C, >45°C Derating Cooling Fan cooling Noise (dB) ≤55dB Communication with BMS RS485/CAN Machine Dimension (W*H*D)(mm) 446*692*260 (excluding connectors and racks) Package Dimension (W*H*D)(mm) 567*816*404 N.W(kg) 38 G.W(kg) 42 Protection Degree IP66 Installation Style Wall-mounted Warranty 5 Years the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy CERTIFICATION & STANDARDS CE-EMC LVD (EN6100-6-3, EN6100-6-1 EN IEC 62109-1, EN IEC 62109-2); CE-LVD(EN 62477-1) ; IEC 60529; EN50549-1; Poland Type A, (NC RfG:2016, PSE:2018, PTPiREE:2021)C10/C11; UNE217001-2020; UNE217002-2020, NTS-631 (Type A); G98 G99
