■ Portable and easy carry ■ Huge AC output ■ Seamless 24/7 UPS, Plug and play home backup power ■ Multiple Charging Ways Available: AC Charging, Solar Charging, Car Charging MODEL EM1024S EM1548S Nominal Battery System Voltage 24VDC 48VDC INVERTER OUTPUT Rated power 1000W 1500W Output voltage waveform Pure Sine Wave Output voltage regulation 110V±5%; 230V±5% Output frequency 50Hz / 60Hz (±0.2Hz) Peak efficiency 2000W (max) 3000W (max) Standby Consumption 110V< 12W; 220V< 25W PV INPUT Max solar power input 600W 1000W PV max charging current 25A 20A Max efficiency 95.0% (max) PV array open circuit voltage 60V (max) 80V (max) PV Array MPPT Voltage Range 12~60V 12~80V AC INPUT AC input voltage 110VAC ±5%; 230VAC ±5% Acceptable input voltage range 90-130VAC; 180-260VAC Nominal input frequency 50Hz / 60Hz (Auto detection) Transfer time ≤15ms AC CHARGE Charging current @ Nominal input voltage 600W@110V; 600W@220V 1000W@110V; 1000W@220V Charging Algorithm Equalize charge – Trickle charge OUTPUT AC output 110Vac (Socket *3pcs); 230Vac (Socket *2pcs) Car charger output (cigarette lighter) 120W DC output (DC5521) 60W*2 USB-C(Type-C) PD18W*1 PD60W*2 USB-A(USB) QC18W*3 LED (white light) 2W LITHIUM BATTERY Energy 1280Wh 1433Wh Nominal voltage 25.6V 51.2V Battery capacity 50Ah 28Ah Protection board 100A 80A Standard charging & discharge current Charging@25A; discharge@50A Charging@20A; discharge@40A Operation temperature -10°C to 45°C -10°C to 45°C Storage temperature -10°C to 55°C -10°C to 55°C MECHANICAL SPECIFICATIONS Machine Dimension (W*H*D)(mm) 440*233.2*263.3 Package Dimension (W*H*D)(mm) 504*314.5*345 N.W(kg) 17.9 19.5 Standard Warranty Inverter: 2 years ; Lithium battery: 5 years CERTIFICATION & STANDARDS CE-EMC LVD (EN55032 A11, EN55035 A11, EN61000-3-2 A1, EN61000-3-3 A1, EN IEC62368-1 A11) Rohs2.0(2011/65/EU)(2015/863/EU)
